Hydraulic pump unit


Hydraulic pump station is the core of the hydraulic oil supplying, so that hydraulic remote control valve can be actuated automatically. The high qualified accessories are selected, which results in the stable working state. The design of the pump station refers to the advanced drawing and scheme, and all the accessories of the whole unit are arranged to easy to be checked and repaired. Without noise, the oil pump is installed inside the oil tank. Standard pump station unit is equipped with 75, 150, 220, and 400L oil tank.




Technical data：

TYPE

DJC-HP

Supply Power

AC220V/380V,50Hz

Rating Pressure

80KG/cm2 ,135KG/cm2

Test Pressure

220KG/cm2

Material

Carbon steel

Weight

150KG~400KG

Oil Chest Cubage

75-400L
